BX, HBX & HDBX Series Towers for 2024
Premium Laser Cut USA Made Self Supporting Towers
From 24 to 72 feet - Galvanized Steel Towers
Please Confirm by E-Mail Your Shipping Cost.
Start Here with your copy of our Understanding TIA-222-Revision G Flier
BX Catalog in Adobe.pdf (Old Data, Still OK)
Legacy BX Catalog for Reference
Order Form For Towers & Accessories
You Have A Used BX and Need To ID It?
Bolt Torque Spec's for BX Hardware
Please contact us for a quote. E-mail or call: 603-425.9876
Tell us which tower/parts you need & your "ship to" city & zip code.
If you can supply a local "Commercial Address" for delivery, that saves on shipping.
Also if you have access to a truck, you can pick up your order at the closest Terminal. That saves shipping costs.
These towers are built to order with a 2-4 week lead time average. Please figure that in your plan.
We will send you a material & freight quote generally the same day!
It is always best to contact us by E-mail
2024 Parts Price Sheet
Discount Prices, Factory Direct Shipping
Based on 04/2022 Factory Pricing
Note: New Pricing in effect. If your collecting bids, be sure it's from a Current Price sheet!
|
Old BX Part Number |
Order the New T.S. Part Number |
Description |
Weight, Lbs. |
Manufacturer's Dealer Net |
Sandown Wireless Dealer Net |
| BX1A | TBX1A | OFFSET TOP SECTION W/PLATES & HARDWARE (Note: Not drilled for the ROHN Bearings) | 33.00 | $708.00 | $620.00 |
| BX2 | TBX2 | STANDARD OFFSET SECTION | 33.00 | $557.00 | $488.00 |
| BX2A | TBX2A | OFFSET TOP SECTION W/PLATES & HARDWARE | 38.00 | $745.00 | $652.00 |
| BX24 | TBX24 | 24' STANDARD TOWER ASSEMBLY W/M8 (ORDER BASE STUBS, BXB3 SEPARATELY) | 101.00 | $1,825.00 | $1,597.00 |
| BX3 | TBX3 | STANDARD OFFSET SECTION | 35.00 | $591.00 | $518.00 |
| BX3A | TBX3A | OFFSET TOP SECTION W/PLATES & HARDWARE | 40.00 | $782.00 | $685.00 |
| BX32 | TBX32 | 32' STANDARD TOWER ASSEMBLY W/M8 (ORDER STUBS, BXB4 AS A SEPARATE ITEM) | 158.00 | $2,430.00 | $2,171.00 |
| BX4 | TBX4 | STANDARD OFFSET SECTION | 57.00 | $598.00 | $524.00 |
| BX40 | TBX40 | 40' STANDARD TOWER ASSEMBLY W/M8 (ORDER STUBS, BXB5 AS A SEPARATE ITEM) | 221.00 | $3,054.00 | $2,765.00 |
| BX48 | TBX48 | 48' STANDARD TOWER ASSEMBLY W/M8 (ORDER STUBS, BXB6 AS A SEPARATE ITEM) | 294.00 | $3,675.00 | $3,216.00 |
| BX5 | TBX5 | STANDARD OFFSET SECTION | 63.00 | $698.00 | $611.00 |
| BX56 | TBX56 | 56' STANDARD TOWER ASSEMBLY W/M8 (ORDER STUBS, BXB7/8 AS A SEPARATE ITEM) | 369.00 | $4,393.00 | $3,844.00 |
| BX6 | TBX6 | STANDARD OFFSET SECTION | 73.00 | $808.00 | $707.00 |
| BX64 | TBX64 | 64' STANDARD TOWER ASSEMBLY W/M8 (ORDER STUBS, BXB7/8 AS A SEPARATE ITEM) | 452.00 | $5,253.00 | $4,597.00 |
| BX72 | TBX72 | 72' STANDARD TOWER ASSEMBLY (BX64) WITH SECTION-8 STRAIGHT AND M8 MAST (ORDER STUBS, BXB7/8 AS A SEPARATE ITEM) | 535.00 | $6,536.00 | $5,720.00 |
| BX7 | TBX7 | STANDARD OFFSET SECTION | 75.00 | $1,107.00 | $969.00 |
| BX8 | TBX8 | STANDARD OFFSET SECTION | 83.00 | $1,221.00 | $1,069.00 |
| BX8-Straight | TBX8ST | Custom EXTENSION #8 SECTION (Bottom) Installs under section 8, Makes the BX64, HBX56 and HDBX48, 8 feet taller. | 85.00 | $1,283.00 | $1,123.00 |
| BXB3 | BS-3 | 4' CONCRETE BASE STUBS (SET/3) W/ACWS - Fits Bottom Section #3 | 13.00 | $210.00 | $184.00 |
| BXB4 | BS-4 | 4' CONCRETE BASE STUBS (SET/3) W/ACWS - Fits Bottom Section #4 | 17.00 | $228.00 | $200.00 |
| BXB5 | BS-5 | 4' CONCRETE BASE STUBS (SET/3) W/ACWS - Fits Bottom Sections #5 | 22.00 | $245.00 | $215.00 |
| BXB6 | BS-6 | 4' CONCRETE BASE STUBS (SET/3) W/ACWS - Fits Bottom Sections #6 | 23.00 | $263.00 | $231.00 |
| BXB7/8 | BS-7/8 | 4' CONCRETE BASE STUBS (SET/3) W/ACWS - Fits Bottom Section #7 and #8 and #TBX8ST | 25.00 | $280.00 | $245.00 |
| BXHC36 | HB36 | SELF SUPPORTING HINGED CONCRETE BASE W/ACWS (For Towers using a base section #3 to #6) | 27.00 | $608.00 | $532.00 |
| BXHC78 | HB78 | SELF SUPPORTING HINGED CONCRETE BASE W/ACWS (For Towers using a base section #7 to #8) | 56.00 | $798.00 | $615.00 |
| BXMK2 | MK2 | HARDWARE MAST KIT (Mast Clamps for the Light Duty mast supplies with the "BX" series towers) | 2.00 | $94.50 | $83.00 |
| BXR1A | RP1A | ROTOR PLATE (REPLACEMENT) For Top Section #1 | 1.50 | $42.85 | $38.00 |
| BXR2A | RP2A | ROTOR PLATE (REPLACEMENT) For Top Section #2 | 2.00 | $98.73 | $87.00 |
| BXR3A | RP3A | ROTOR PLATE (REPLACEMENT) For Top Section #3 | 2.50 | $98.75 | $88.00 |
| BXSK1 | SK1 | EXTRA STEP KIT FOR SECTION 1 | 1.00 | $25.22 | $23.00 |
| BXSK2 | SK2 | EXTRA STEP KIT FOR SECTION 2 | 1.00 | $27.38 | $24.00 |
| BXSK3 | SK3 | EXTRA STEP KIT FOR SECTION 3 | 1.00 | $28,68 | $26.00 |
| BXSM | SM | UNIVERSAL SIDE MOUNT | 12.00 | $230.00 | $202.00 |
| BXT1A | TP1A | TOP PLATE (REPLACEMENT) For Top Section #1 Top Plate Sheet - All | 2.00 | $51.43 | $45.00 |
| BXT2A | TP2A | TOP PLATE (REPLACEMENT) For Top Section #2 | 2.00 | $76.00 | $67.00 |
| BXT3A | TP3A | TOP PLATE (REPLACEMENT) For Top Section #3 | 2.50 | $91,75 | $81.00 |
| EFBX | TEFBX | Erection Fixture Kit. Requires that you supply a 10-12 foot 2" OD pipe. All other components are in the kit. (Hey, just buy the tilt base, all you need is a pulley and rope) Note: Special Order Part, 6 months lead time! | N/A | Call for Quote | |
| FL (Heavy Duty Mast Clamp) Recommended if you have a large antenna. (2) Req. | TC | Heavy Duty Mast Clamp Assembly (This is a optional heavier clamp. Use two to mount high wind load antennas) Cast Metal, works good with the M200H. (The ID of the center hole is specified to be 2.25" so that's the max. You will need to order 2 clamps for most installations. | 3.00 | $75.00 | $66.00 |
| HBX24 | THBX24 | 24' HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB4 and MAST AS SEPARATE ITEMS) | 143.00 | $1,845.00 | $1,615.00 |
| HBX32 | THBX32 | 32' HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB5 and MAST AS SEPARATE ITEMS) | 193.00 | $2,481.00 | $2,171.00 |
| HBX40 | THBX40 | 40' HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB6 and MAST AS SEPARATE ITEMS) | 266.00 | $3,159.00 | $2,765.00 |
| HBX48 | THBX48 | 48' HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB7/8 and MAST AS SEPARATE ITEMS) | 341.00 | $3,963.00 | $3,468.00 |
| HBX56 | THBX56 | 56' HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB7/8 and MAST AS SEPARATE ITEMS) | 424.00 | $4,822.00 | $4,220.00 |
| HDBX24 | THDBX24 | 24' EXTRA HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB5 and MAST AS SEPARATE ITEMS) | 171.00 | $1,992.00 | $1,743.00 |
| HDBX32 | THDBX32 | 32' EXTRA HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB6 and MAST AS SEPARATE ITEMS) | 231.00 | $2,739.00 | $2,397.00 |
| HDBX40 | THDBX40 | 40' EXTRA HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB7/8 and MAST AS SEPARATE ITEMS) | 305.00 | $3,542.00 | $3,100.00 |
| HDBX48 | THDBX48 | 48' EXTRA HEAVY DUTY TOWER ASSEMBLY (ORDER BASE STUBS, BXB7/8 and MAST AS SEPARATE ITEMS) | 397.00 | $4,402.00 | $3,852.00 |
| TB3 | TB3 | THRUST BEARING FOR 2" OD Max. MAST (Generally the M200H) Price assumes shipping with a BX tower from OH shop | 3.08 | $224.00 | |
| TB4 | TB4 | THRUST BEARING FOR 3" OD Max. MAST (Usually too much mast for a BX, Not Recommended) Price assumes shipping with a BX tower from OH shop | 3.20 | $300.00 | |
| M8 | P8114 | 8' MAST, PRE-GALVANIZED (This Light Duty Mast is included with all standard "BX" tower kits only) | 6.50 | $53.88 | $48.00 |
| - | AB30 | 30 Inch X 1" Base Bolt as used in the HB78, Just a Bolt, no other Hardware (Fits Section 7 & 8 Base ) | - | Call for Quote | |
| - | AB20 | 20 Inch X 3/4" Base Bolt as used in the HB36, Just a Bolt, no other Hardware (Fits Section 3-6 Base ) | - | Call for Quote | |
| - | HB78-Reinstall | Complete Reinstall kit of the embedded material in the HB78 base. Used when moving a tower. Just material embedded in the Concrete | - | Call for Quote | |
| - | HB36-Reinstall | Complete Reinstall kit of the embedded material in the HB36 base. Used when moving a tower. Just material embedded in the Concrete | - | Call for Quote | |
| - | N34 | 3/4 Inch Heavy Duty Base Nut, as used in the HB36 Hinged Base | Call for Quote | ||
| - | N1 | 1 Inch Heavy Duty Base Nut, as used in the HB78 Hinged Base | Call for Quote | ||
| HWP-BX24 | HWP-TBX24 | Complete Tower Hardware Kit for the BX24 (Note, Hardware kits are included with new towers) | Approx. 10.00 | $126.65 | $111.00 |
| HWP-BX32 | HWP-TBX32 | Complete Tower Hardware Kit for the BX32 | Approx. 10.00 | $146.90 | $129.00 |
| HWP-BX40 | HWP-TBX40 | Complete Tower Hardware Kit for the BX40 | Approx. 10.00 | $165.83 | $146.00 |
| HWP-BX48 | HWP-TBX48 | Complete Tower Hardware Kit for the BX48 | Approx. 10.00 | $186.24 | $163.00 |
| HWP-BX56 | HWP-TBX56 | Complete Tower Hardware Kit for the BX56 | Approx. 10.00 | $201.00 | $177.00 |
| HWP-BX64 | HWP-TBX64 | Complete Tower Hardware Kit for the BX64 | Approx. 10.00 | $264.83 | $232.00 |
| HWP-HBX24 | HWP-THBX24 | Complete Tower Hardware Kit for the HBX24 | Approx. 10.00 | $130.00 | $113.75 |
| HWP-HBX32 | HWP-THBX32 | Complete Tower Hardware Kit for the HBX32 | Approx. 10.00 | $150.00 | $132.00 |
| HWP-HBX40 | HWP-THBX40 | Complete Tower Hardware Kit for the HBX40 | Approx. 10.00 | $169.30 | $149.00 |
| HWP-HBX48 | HWP-THBX48 | Complete Tower Hardware Kit for the HBX48 | Approx. 10.00 | $195.00 | $171.00 |
| HWP-HBX56 | HWP-THBX56 | Complete Tower Hardware Kit for the HBX56 | Approx. 10.00 | $223.00 | $196.00 |
| HWP-HDBX24 | HWP-THDBX24 | Complete Tower Hardware Kit for the HDBX24 | Approx. 10.00 | $140.73 | $124.00 |
| HWP-HDBX32 | HWP-THDBX32 | Complete Tower Hardware Kit for the HDBX32 | Approx. 10.00 | $170.25 | $149.00 |
| HWP-HDBX40 | HWP-THDBX40 | Complete Tower Hardware Kit for the HDBX40 | Approx. 10.00 | $198.25 | $174.00 |
| HWP-HDBX48 | HWP-THDBX48 | Complete Tower Hardware Kit for the HDBX48 | Approx. 10.00 | $215.00 | $189.00 |
| BXAC3-3 Data Sheet | ACP3-3 | 24' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 3, Custom Made, 3 week lead Time Minimum | 27.0 | $672.12 | $589.00 |
| BXAC3-4 Data Sheet | ACP3-4 | 32' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 4, Custom Made, 3 week lead Time Minimum | 32.0 | $739.83 | $648.00 |
| BXAC3-5 Data Sheet | ACP3-5 | 40' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 5, Custom Made, 3 week lead Time Minimum | 44.0 | $838.93 | $735.00 |
| BXAC3-6 Data Sheet | ACP3-6 | 48' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 6, Custom Made, 3 week lead Time Minimum | 50.0 | $842.00 | $737.00 |
| BXAC3-7 Data Sheet | ACP3-7 | 56' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 7, Custom Made, 3 week lead Time Minimum | 66.0 | $938.42 | $822.00 |
| BXAC3-8 Data Sheet | ACP3-8 | 64' Anti-Climb Kit (Set of 3) Instruction Sheet Fits Base Section 8, Custom Made, 3 week lead Time Minimum | 76.00 | $997.85 | $873.00 |
| BXAC3-8S | ACP3-8S | AntiClimb Kit for the BX8-Straight Section, Fits Base Section 8-Straight, Custom Made, 3 week lead Time Minimum | 83.00 | Call for Quote |
 |
All tower kits are supplied with their complete hardware kits. |
|
All standard "BX" tower kits are supplied with a standard set of clamps and a top mast . The HBX and HDBX are not supplied with a mast. Generally the M200H with a pair of "FL" clamps is ordered for those. The top plates are drilled for the supplied standard mast & clamp set. To use the TB3 or TB4 you will need to drill your own mounting holes. |
|
You must order concrete base stubs or hinged base separate when you place your order. |
|
As of 04/25/2022 THE POSTED PRICING IS CORRECT AND ACCURATE. |
|
For Site Specific State Stamped Engineering Drawings contact "The Paul J. Ford Company": Tel: 614-221-6679 We cannot supply drawings for this model tower from the manufacturer. |
|
We actually supply needed services to get your tower approved not just a low price & jacked up shipping charges like some others do. |
|
It's one of those "You Get What You Pay For" things. We will be here when you need us next year. |
BX Install Video: http://www.youtube.com/watch?v=VzWYuS_o6kI
Another Install Video: http://www.youtube.com/watch?v=Qe7-GxiqTro
New Catalog / Instruction / Specification Sheets for 2021
Order Form For ROHN Towers & Accessories
Sample State Stamped Engineering Drawing, HDBX-48
